Description
195/50R13C Wheel & Tyre Assembly 5×6.5″ PCD, 104/101N, ET7 (7mm offset)
This 195/50R13C Wheel & Tyre Assembly 5x112mm PCD wheel and tyre assembly is commonly found on older Ifor Williams and EquiTrek trailers.
The wheel rim has a 6.5″ PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 104/101N rating, meaning it has a load index of 900kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info).
These wheels & tyres are ideally suited for use on older EquiTrek DayTreka, NightTreka and StarTreka horseboxes – please check before ordering.
195/50R13C Wheel & Tyre Assembly 5×6.5″ PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | 6.0Jx13H2 | ||
| Wheel Rim Colour | Silver | ||
| No. of Studs and size of stud | 5 x M16 | ||
| PCD (pitch circle diameter) |
6.5″ |
||
| Centre Hole Dia | 114mm |
||
| Stud Hole Dia | 18mm | ||
| Offset | ET7 | ||
| Tyre Specification | |||
| Tyre Size | 195/50R13C | ||
| Overall Tyre Diameter | 526mm diameter | ||
| Tyre Type | Commercial | ||
| Ply Rating | 8ply |
||
| Load Index | 104/101 | ||
| Max Load | 900kg | ||
| Speed Symbol | N | ||
| Max Tyre Pressure | 95 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
