165R13C Wheel & Tyre Assembly 4x100mm PCD, 96/94N, ET30 (30mm offset) – Compass
This 165R13C Wheel & Tyre Assembly 4x100mm PCD wheel and tyre assembly is commonly found on trailers and caravans with the 4 stud 100mm PCD configuration.
The wheel rim has a 100mm PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 96/94N rating, meaning it has a load index of 710 / 670kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info). The 710kg rating is based on a single axle; the 670kg figure is when used in a twin axle configuration.
These wheels & tyres are ideally suited for use on 1300kg single axle or 2600kg twin axle trailers.
165R13C Wheel & Tyre Assembly 4×5.5″ PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | 4.5Jx13H2 | ||
| Wheel Rim Colour | Silver | ||
| No. of Studs & size of Stud | 4 x M12 | ||
| PCD (pitch circle diameter) |
100mm |
||
| Centre Hole Dia | 60mm |
||
| Stud Hole Dia | 13mm | ||
| Offset | ET30 | ||
| Tyre Specification | |||
| Tyre Size | 165/80R13 | ||
| Overall Tyre Dia | 615mm (24.25 inches) |
||
| Tyre Type | Commercial | ||
| Ply Rating | 8pr | ||
| Load Index | 96/94 | ||
| Max Load | 710kg / 670kg | ||
| Speed Symbol | N | ||
| Max Tyre Pressure | 65 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
