Description
195/60R12C Wheel & Tyre Assembly 5×6.5″ PCD, 104/101N, ET7 (7mm offset)
This 195/60R12C Wheel & Tyre Assembly 5×6.5″ PCD is commonly found on 3500kg Ifor Williams trailers such as CT166, CT167, GP106, GP126, GP146, LM85, LM105, LM125, LM106, LM126, LM146, LM166, LM186, LM127, LM147, LM167, LM187, LM146/B, LM147/B, LM166/B, LM167/B, TT3017, TT3621
The wheel rim has a 6.5″ PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 104/102N rating, meaning it has a load index of 900kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info).
195/60R12C Wheel & Tyre Assembly 5×6.5″ PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | Â 6.0Jx12H2 | ||
| Wheel Rim Colour | Â Silver | ||
| No. of Studs and size of stud | Â 5 x M16 | ||
| PCD (pitch circle diameter) |
 6.5″ (165.1mm) |
||
| Centre Hole Dia | Â 114mm |
||
| Stud Hole Dia | Â 18mm | ||
| Offset | Â ET7 | ||
| Tyre Specification | |||
| Tyre Size | Â 195/60R12C | ||
| Overall Tyre Diameter | Â 545mm diameter | ||
| Tyre Type | Â Commercial | ||
| Ply Rating | Â 8ply |
||
| Load Index | Â 104/102 | ||
| Max Load | Â 900 / 825kg | ||
| Speed Symbol | Â N | ||
| Max Tyre Pressure | Â 95 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
