20.5×8-10 Flotation Wheel & Tyre Assembly 100mm PCD, 77M, ET-4
This 20.5×8-10 Flotation Wheel & Tyre Assembly 4x100mm PCD wheel and tyre assembly is commonly found on Ifor Williams P6 trailers (newer versions) as well as others by Meredith & Eyre.
The wheel rim has a 100mm PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 77M rating, meaning it has a load index of 412kg and a speed rating of 81mph (see our posts on load index & speed ratings for more info).
These wheels & tyres are ideally suited for use on 750kg single axle unbraked trailers and small boat trailers.
20.5×8-10 Flotation Wheel & Tyre Assembly 4x100mm PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | 6.0Jx10 | ||
| Wheel Rim Colour | Silver | ||
| No. of Studs and size of stud | 4 x M12 | ||
| PCD (pitch circle diameter) |
100mm |
||
| Centre Hole Dia | 60mm |
||
| Stud Hole Dia | 13mm | ||
| Offset | ET-4 | ||
| Tyre Specification | |||
| Tyre Size | 20.5×8-10 | ||
| Overall Tyre Diameter | 555mm diameter | ||
| Tyre Type | Radial | ||
| Ply Rating | 4 Ply |
||
| Load Index | 77 | ||
| Max Load | 412kg | ||
| Speed Symbol | M | ||
| Max Tyre Pressure | 35 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
