Description
195/50R13C Wheel & Tyre Assembly 5x112mm PCD, 104/101N, ET30 (30mm offset)
This 195/50R13C Wheel & Tyre Assembly 5x112mm PCD wheel and tyre assembly is commonly found on newer EquiTrek twin axle horseboxes (StarTreka, DayTreka, NightTreka).
The wheel rim has a 112mm PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 104/102N rating, meaning it has a load index of 900kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info).
These wheels & tyres are ideally suited for use on modern EquiTrek DayTreka, NightTreka and StarTreka horseboxes.
195/50R13C Wheel & Tyre Assembly 5x112mm PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | Â 6.0Jx13H2 | ||
| Wheel Rim Colour | Â Silver | ||
| No. of Studs and size of stud | Â 5 x M12 | ||
| PCD (pitch circle diameter) |
 112mm |
||
| Centre Hole Dia | Â 66mm |
||
| Stud Hole Dia | Â 15mm | ||
| Offset | Â ET30 | ||
| Tyre Specification | |||
| Tyre Size | Â 195/50R13C | ||
| Overall Tyre Diameter | Â 526mm diameter | ||
| Tyre Type | Â Commercial | ||
| Ply Rating | Â 8ply |
||
| Load Index | Â 104/101 | ||
| Max Load | Â 900kg | ||
| Speed Symbol | Â N | ||
| Max Tyre Pressure | Â 94 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
