Description
155/70R12C Wheel & Tyre Assembly 5x112mm PCD, 104/102N, ET20 (20mm offset)
This 155/70R12C Wheel & Tyre Assembly 5x112mm PCD wheel and tyre assembly is commonly found on Brian James 3500kg twin axle trailers.
The wheel rim has a 112mm PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 104/102N rating, meaning it has a load index of 900kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info).
These wheels & tyres are ideally suited for use on 1800kg single axle braked and 3500kg twin axle braked trailers.
155/70R12C Wheel & Tyre Assembly 5x112mm PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | 4.5Jx12H2 | ||
| Wheel Rim Colour | Silver | ||
| No. of Studs and size of stud | 5 x M12 | ||
| PCD (pitch circle diameter) |
112mm |
||
| Centre Hole Dia | 66mm |
||
| Stud Hole Dia | 15mm | ||
| Offset | ET20 | ||
| Tyre Specification | |||
| Tyre Size | 155/70R12C | ||
| Overall Tyre Diameter | 530mm diameter | ||
| Tyre Type | Commercial | ||
| Ply Rating | 8ply |
||
| Load Index | 104/102 | ||
| Max Load | 900kg | ||
| Speed Symbol | N | ||
| Max Tyre Pressure | 90 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
