Description
145R10C Wheel & Tyre Assembly 4x100mm PCD, 84/82N, ET0 (No offset)
This 145R10C Wheel & Tyre Assembly 4x100mm PCD wheel and tyre assembly is commonly found on unbraked and braked trailers running 100mm PCD wheel hubs.
The wheel rim has a 100mm PCD – the “Pitch Circle Diameter”. This is the diameter of an “imaginary” circle that would intersect all of the wheel studs / bolts centrally (see our page on PCD for more info).
The tyre is a 84/82N rating, meaning it has a load index of 500kg and a speed rating of 87mph (see our posts on load index & speed ratings for more info).
These wheels are ideally suited for use on 750kg unbraked or 1000kg single axle and 2000kg twin axle braked trailers.
145R10C Wheel & Tyre Assembly 4x100mm PCD Detailed Specifications –
| Trailer Wheel Specification | |||
| Wheel Rim Size | 3.5Bx10H2 | ||
| Wheel Rim Colour | Silver | ||
| No. of Studs and size of stud | 4 x M12 | ||
| PCD (pitch circle diameter) |
100mm |
||
| Centre Hole Dia | 60mm |
||
| Stud Hole Dia | 13mm | ||
| Offset | ET0 | ||
| Tyre Specification | |||
| Tyre Size | 145R10C | ||
| Overall Tyre Diameter | 510mm diameter | ||
| Tyre Type | Commercial | ||
| Ply Rating | 8ply |
||
| Load Index | 84/82 | ||
| Max Load | 500kg | ||
| Speed Symbol | N | ||
| Max Tyre Pressure | 50 PSI | ||
* Photo shown is a generic image, you are only purchasing ONE assembly *
